Usually ships within a few days.
No Discounts Possible With This Product.
Affirm Cannot Be Used With This Product.
The new Violectric DHA V226 headphone amplifier with DAC is a high-quality compact solution for demanding hi-fi tasks. The high-resolution converter unit accepts digital audio with up to 32 bit at 384 kHz and DSD 256 via USB-C. The converted signal is then output by a headphone amplifier in top Violectric quality to balanced or unbalanced headphones via 4-pin XLR, 4.4 mm Pentaconn or 6.3 mm jack. The innovative circuit enables the operation of a wide variety of headphone types, from high-impedance models to low-impedance versions and magnetostats. Lowest noise and minimal distortion allow an exceptionally clear, detailed reproduction. Two analog RCA inputs and an analog RCA output integrate the DHA V226 effortlessly into a hi-fi setup and make it the central hub.
Features:
- balanced inputs via gold-plated Neutrik XLR sockets
- unbalanced inputs via gold-plated RCA sockets
- 1 digital input, USB-C, with up to 32 bit and up to 384 kHz for PCM signals, DSD 64 - 256
- PRE-GAIN: amplification can be adjusted in 7 stages on the back
- Powerful balanced stereo amplifier (4 output stages)
- Compact and extremely robust aluminum housing
- Made in Germany
Specifications:
| Item number: |
1008175 |
| Max. Input Voltage |
+21 dBu |
| dimensions |
165 x 54 x163 mm (WxHxD) |
| Dynamic range |
> 131 dB (A-bew.) |
| Attenuator Make |
ALPS RK27 |
| Volume Knob |
38 mm Aluminum |
| housing form |
Desktop |
| output impedance |
< 0,5 Ohm balanced / 0,25 Ohm unbalanced |
| Input Sensitivity |
+6 dBu |
| Input Impedance |
10 kOhm |
| color |
black |
| signal-to-noise ratio (SNR) |
< -102 dBu (A-bew.) |
| power supply |
Internal 230 V / 115 V AC |
| frequency range |
5 Hz - 150 kHz |
| crosstalk |
-100 / -95 dB (1 kHz / 15 kHz) |
