Luxman does not permit any product to be ordered via an online shopping cart. Please contact us by phone or email for more information or to order. Thank you very much.
The player includes MQA technology, which enables you to play back MQA-CDs as well as MQA audio files up to 24-bit transferred via USB, optical and coaxial inputs. The USB input also supports PCM data up to 384 kHz/32-bit and DSD data up to 11.2 MHz while the optical and coaxial inputs accept PCM signals up to 192 kHz/24-bit. In addition to conventional “isochronous” file transfers at fixed bitrates, the USB input supports four modes of Bulk Pet* high-resolution audio file transfer. Bulk Pet, optimizes data packaging and delivery to the DAC easing the processing load for both the host CPU and the device CPU enhancing playback stability and ultimately yielding improved sound quality. All signals benefit from a high-precision, low-jitter, low-phase-noise master clock, minimizing noise near the oscillation frequency and optimizing transmission accuracy.
Specifications:
| Applicable disk |
2-channel CD, MQA |
| Analog audio output |
1 x unbalanced line
1 x balanced line |
| Digital audio output |
1 system for coaxial line
1 system for optical line(TOS-LINK) |
| Digital audio input |
1 system for coaxial line
1 systems for optical line(TOS-LINK)
1 USB 192 kHz/32bit PCM and DSD 5.6/2.8MHz |
Output voltage/
output impedance |
Unbalanced 2.4V/ 300Ω
balanced 2.4V/600Ω |
| Frequency response |
CD 5Hz–20kHz
|
| Total harmonic distortion rate |
0.0015% (for CD)
|
|
|
| Power consumption |
18W (Electrical Appliance and Material Safety Law)
1W (at standby) |
| Outside dimensions |
440 (W) x 133 (H) x 410 (D) mm
(terminals and knobs excluded) |
| Weight |
13,2kg
|
