Description
PrimaLuna's EVO 200 Power Amplifier was engineered with the goal of owning a tube amp so simple you would have no excuse not to have your tube dreams come true. Power transformers generate two types of noise, magnetic and acoustic. That's why toroidal power transformers are used in the very best audio products. Output transformers are the most important part of any tube amp. They determine how low the bass will reach and how high the top end goes. PrimaLuna employs Point to Point Wiring on all products. The entire signal path, including resistors and capacitors, is painstakingly hand wired with heavy-gauge cable by craftsman.
Specifications:
| Power: Stereo (8Ω, 1% THD) |
44 watts x 2 (EL34) |
| Power: Mono (8Ω, 1% THD) |
88 watts (EL34) |
| Inputs | Stereo RCA |
| Outputs | 4, 8, & 16 Ω (stereo) 2, 4, & 8 Ω (mono) |
| THD | < 0.1% @ 1W < 2% @ Rated Power |
| Freq. Response | 10Hz-65kHz +/- 1dB 7Hz-95kHz +/- 3dB |
| S/N Ratio | 92dB (stereo) 93dB (mono) |
| Input Sensitivity | 870mV (stereo) 880mV (mono) |
| Input Impedance | 100kΩ |
| Power Consumption | 280 watts |
| Standard Tube Complement | 4 - 12AU7 4 - EL34 |
| Dimensions (WxHxD) | 14.4" x 8.1" x 15.9" |
| Weight | 50.6 lbs |
