Cambridge Audio Edge W Power Amplifier
Cambridge Audio Edge W Power Amplifier
Couldn't load pickup availability
Lighting fast delivery in Canada
Canadian Warranty
Customer Experience
Description
Usually ships within 2 days.
The new Cambridge Audio Edge W power amplifier features just 14 hand-picked components, Edge W has one of the cleanest signal paths available. It delivers our breath-taking, unadulterated British sound – nothing added, nothing taken away. Although minimal in its exterior design, Edge W has some complex audio engineering inside. To remove the barriers between you and your music, we have worked hard to minimise the number of components in the signal path. As a result, Edge W delivers a more faithful reproduction of the original recording; an impressively detailed three-dimensional sound, with striking staging and focus.
The Edge W is remarkably detailed. The sound is finely balanced, with a musical depth and clarity that comes through with every note. It’s all down to how we chose the componentry inside – nothing was picked on price, specs or measured performance. We listened carefully and created our system with components that simply sounded the best. The end result is a power amplifier that truly brings an original recording to life like no other.
We pioneered the use of toroidal transformers in amplifiers, which led to improved performance. In Edge we take this one step further, using opposing symmetry twin toroidal transformers. This cancels out electromagnetic interference whilst offering outstanding power and maintaining consistent tonality, no matter how loud it’s played. Standard Class A amplifier technology wasn’t going to be efficient enough for Edge W. Instead we added a bias voltage to a traditional Class AB design, reducing distortion to inaudible levels. This unique configuration also produces less heat and makes the whole system much more effective.
Specifications:
-
CONTINUOUS POWER OUTPUT 100W RMS into 8 Ohms; 200W RMS into 4 Ohms THD (UNWEIGHTED) <0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms) FREQUENCY RESPONSE <3Hz – >80kHz +/-1dB S/N RATIO (REF 1W INTO 8 OHM) >93 dB CROSSTALK @ 1KHZ < -100dB S/N RATIO (REF FULL POWER) >113 dB INPUT SENSITIVITY Input A1-A2 (unbalanced) 1.09V RMS INPUT IMPEDANCES Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm INPUTS Balanced, Unbalanced OUTPUTS Speakers, Loop out MAX POWER CONSUMPTION 1000W STANDBY POWER CONSUMPTION <0.5W DIMENSIONS 150 x 460 x 405mm (5.9 x 18.1 x 15.9") WEIGHT 23.6kg (51.9lbs) IN THE BOX Edge W Power Amplifier; 1.5M Power Lead; Edge Link Cable; Edge W User Manual, Warranty Card
