Description
Primaluna's EVO100 V2 Phonostage supports both moving magnet and moving coil cartridges. The MM stage offers two capacitance settings, and the MC stage offers three gain, and five input impedance settings. The delicate signals in the MC stage are protected by mechanically decoupling the board.
Specifications:
Output Impedance: 100 Ohm
Input: 1 x Stereo RCA
Output: 1 x stereo RCA
Moving Magnet Stage
Gain: 40 dB
Input Impedance: 47 kOhm
Input Capacitance (Selectable): 47 pF, 100 pF
Moving Coil Stage
Gain (Selectable): 60, 56, 52 dB w/6922 62, 58, 54 dB w/ 12AX7
Input Impedance (Selectable): 50, 100, 200, 500, 1000 Ohm
Tube Complement: 2 x 5AR4, 2 x EL34, 4 x 12AX7 MM, 2 x 12AX7 MC (switchable)
Dimensions (LWH): 15.9" x 11" x 7.5" (405 x 280 x 190 mm)
Weight: 27.9 lb (12.7 kg)
