Shanling EA5 Plus Integrated Amplifier

Description

Usually Ships Within 2 Days.

Shanling's EA5 Plus is an upgraded version of the popular All-in-One home streamer. The EA5 Plus, features a brand-new and more powerful speaker amplifier. Unlike its predecessor, which offered 2x 50W @ 4 Ohm, the EA5 Plus elevates the audio experience with 2x 100W @ 4 Ohm, courtesy of the class-D speaker amplifier 100AS2 from Danish ICEpower. This enhanced power output allows for seamless compatibility with even more demanding speakers, resulting in a noticeable improvement in overall sound quality.

The rest of the Streamer remains identical to the original EA5, combining our closed Android platform with streaming services, an AKM AK4493EQ DAC, a 6.35mm headphone output, and a separated power supply design. This comprehensive feature set makes the EA5 Plus the perfect all-in-one solution for a wide range of Hi-Fi setups. Upgrade your audio system with the EA5 Plus and experience the ultimate in-home streaming and amplification.

Specifications:

• Dimensions: 238 x 188 x 55 mm
• Display: 4.7-inch, 720 x 1280 IPS
• System: Closed Android
• Supported Formats: DSF, DFF, DXD, APE, FLAC, WAV, AIFF, AIF, DTS, MP3, WMA, AAC, OGG, ALAC, MP2, M4A, AC3, M3U, M3U8, ISO (DST not supported)
• Hi-Res Support: 32bit / 768kHz, DSD512
• Adjustable Gain: 4 Gain stages
• DAC: AKM AK4493EQ
• MicroSD Card Support: Up to 2TB
• Digital Filters: 6 pre-set options
• Power Supply: 100V / 110-120V / 220-240V versions (Check with seller)
• Bluetooth Version: 4.2
  • Transmitter: LDAC, LHDC, aptX HD, aptX, SBC
  • Receiver: LDAC, SBC

Speaker Output

• Output Power:
  • 2x 100W @ 40Ω
  • 2x 55W @ 80Ω
• Frequency Response:
  • 20Hz - 20 kHz (-0.5 dB Standard Mode)
  • 20Hz - 20 kHz (+3 dB @ 100 Hz Game Mode)
  • 20Hz - 20 kHz (-3 dB @ 100 Hz Desktop Mode)
• THD+N: 0.002% (A-Weighted @ 0.5V)
• Signal-to-Noise: 105dB @ 80Ω (A-Weighted)
• Noise: 71dB @ 80Ω (A-Weighted)
• Channel Separation: 66dB @ 80Ω

RCA Output

• Output Levels:
  • Low: 0.82V
  • Medium: 1.4V
  • High: 3.0V
  • Turbo: 4.8V
• Frequency Response: 20Hz - 40 kHz (-0.5 dB)
• THD+N: 0.002% (A-Weighted @ 0.5V)
• Signal-to-Noise: 118dB @ 320Ω (A-Weighted)
• Noise: 107 dB (Low Gain)

Headphone Output

• Output Power: 4.3V @ 320Ω (570mW @ 32Ω)
• Frequency Response: 20Hz - 40 kHz (-0.5 dB)
• THD+N: 0.0029% @ 320Ω (A-Weighted @ 0.5V)
• Dynamic Range: 112dB @ 320Ω (A-Weighted High Gain)
• Channel Separation: 70dB @ 320Ω
• Signal-to-Noise: 117dB @ 320Ω (A-Weighted High Gain)
• Noise:
  • 106 dB (Low Gain)
  • 104 dB (Other Gains)
• Output Impedance: 0.80Ω
