PRE-ORDER. STOCK DUE IN MAY.
What if the best sound was achieved decades ago? In 1938, Western Electric manufactured the first type 300-B electron tube. It was a breakthrough power triode, but in those days it hummed away from behind a curtain in early Hollywood sound systems. The same things that served moviegoers back then—low noise, ultra-long life, sonic purity and warmth—made it a standout tube for music lovers and vintage audio collectors as the years passed. Deep into the age of the transistor, communities around the world in search of true, original, high-fidelity sound rediscovered the 300-B and its exceptional performance. New amplifier designs brought the tube front and center, its customary yellow lettering on proud display.
Sometimes, the old ways are the best.
Today, the 300-B is re-entering production at the Rossville Works. Our new manufacturing home was custom-built to master the dozens of individual demands of tube making, from sealing the iconic glass bulb to the complex metallurgic processes within. We’ve modernized the production line here and there to establish forward momentum at a company with 150 years of history. Western Electric believes twenty-first century listeners deserve twenty-first century manufacturing standards.
Balanced, Powerful and Refined
The WE 300-B’s sound is balanced, powerful and refined with quality bass from the lowest frequencies through the upper bass. The midrange above is a thing of beauty; dulcet tones, seductive vocals, instruments of all types dimensional and present, all heightening the participatory elements of music.
Burnished and Beautifully Seductive
High frequencies are at once transparent, lovely, sweet, burnished and beautifully seductive. The air and space between performers is extraordinary, performers appear on a quiet and focused soundstage whose width and depth are masterfully rendered. You don’t have to search to find the sweet spot with a WE 300-B amplifier, it’s all around you.
Moderate power, filamentary triodes for class-A service.
Audio-frequency amplifier in positions where power outputs of approximately ten watts or less are required at relatively low plate voltages.
Dimensions, outline diagrams of the tubes and bases, and the arrangement of electrode connections to the base terminals are shown in Figures 1 and 2.
BASE AND MOUNTING
These vacuum tubes employ medium, four-pin thrust type bases suitable for use in Western Electric 143B or similar sockets. The 300-B tube has the bayonet pin so located that it may also be mounted in a Western Electric 100M, 115B or similar socket.
The tubes may be mounted in either a vertical or horizontal position. If mounted In a horizontal position, the plane of the filament, which is indicated In Figure 2, should be vertical.
AVERAGE DIRECT INTERELECTRODE CAPACITANCES
Grid to plate 15 µµf.
Grid to filament 9 µµf.
Plate to filament 4.3 µµf.
