Audeze

Audeze LCD-4z Headphones

Audeze LCD-4z Headphones

Regular price $5,499.00
Regular price Sale price $5,499.00
Sale Featured Sold out
Shipping calculated at checkout.
LCD-4z

Lighting fast delivery in Canada

Canadian Warranty

Customer Experience

View full details

Description


PLEASE CONTACT US FOR AVAILABILITY.





The LCD-4z is engineered with a new magnesium housing to produce a light-weight, visually appealing headphone, the LCD-4z maintains the sound signature of LCD-4. The LCD-4z features a dark sleek aesthetic with gold accents. The magnesium rings of the LCD-4z are designed to be strong, lightweight, and non-resonant for a very clean output. The LCD-4z features our most advanced diaphragm design. Benefits include faster response for better transient/impulse response, imaging, and the flattest, deepest, most accurate bass response of any headphone available.

Double Fluxor™ Magnet Arrays bring the magnetic flux to 1.5 Tesla, nearly doubling the power driving the diaphragm for improved transient response and far greater resolution. Combining our Fluxor™ magnet arrays, nano-scale diaphragm, Fazors, Uniforce voice coil, and other features, the LCD-4 and LCD-4z give you even lower distortion and greater accuracy - usually 1/10th the distortion of conventional headphones. The LCD-4z headphone is thoroughly engineered and meticulously hand-built using the finest materials combined with cutting-edge planar magnetic technology. We closely match transducers to within +/- 1 dB.

Features
  • Planar magnetic drivers for better dynamics and frequency response
  • Premium leather for style and durability
Audeze Technology
  • Flux density 1.5 Tesla
  • Large ultra-thin nano grade Uniforce diaphragms
  • Double Fluxor™ magnetic arrays
  • Fazor elements



The Audeze LCD Series Premium cable features cryogenically treated four conductor stranded wire, each wire consisting of a large number of extremely fine strands of single-crystal OCC copper with a combined cross section equivalent to AWG 20 that ensures low resistance and negligible signal loss. The white/black cable uses silver-plated copper strands. Crystals within strands are oriented in a specific pattern to provide the best possible signal transmission.

  • Very flexible, tangle free
  • Non-microphonic jacket
  • Length: 2.5m; Weight: 110 g

Connectors:

  • 1/4" (6.3mm) stereo OR 4-pin balanced XLR plug for connection to amplifier
  • 2 x 4-pin mini XLR for headphone earcup connection

Electrical Specifications:

  • Resistance: 12 milliohms per foot
  • Capacitance: 10 picofarads per foot
  • Inductance: 0.15 microhenrys per foot
  • Dielectric strength:  1000V



PLEASE indicate choice of Balanced 4 pin XLR or 6.3mm Single Ended Connector in the check out notes. Thank you.







LCD-4z Specifications:
Style Over-ear, open-back
Transducer type Planar magnetic
Magnetic structure Proprietary magnet array
Phase management FAZOR
Magnet type Neodymium N50
Diaphragm type Nano-scale Uniforce™
Transducer size 106 mm
Maximum power handling 15W
Maximum SPL >130dB
Frequency response 5Hz – 20kHz
THD <0.1% @ 100dB
Impedance 15 ohms
Sensitivity 98 dB/1mW (at Drum Reference Point)
Voltage sensitivity 107 dB/1V (at Drum Reference Point)
Minimum power requirement >100mW
Recommended power level 1 - 4W
