Featuring a chic, compact design, the DALI KATCH ONE features no fewer than 10 built-in drivers, perfectly matched with a powerful 4x 50W amplifier. Driving the KATCH ONE are 4 x 50 watts peak, closed loop Class-D amplifiers. Utilising DSP for the active crossover, the amplifiers are directly connected to the drivers, maximising the performance.
With soft dome tweeters keeping sound clean and detailed, four large passive drivers work alongside four active woofers to deliver bass that's tight, punchy and precise, all combining to providing the perfect audio experience.
Elegant and easy to install, the DALI KATCH ONE comes with all the inputs you could ever need, including HDMI, 2x Optical, Analogue, not to mention Bluetooth (AAC and aptX). With 5 different audio inputs, the KATCH ONE will connect to any audio device. This includes four ways to connect to your TV. Not to mention the ample possibilities to connect music streaming devices. Furthermore the KATCH ONE has auto signal detect on all inputs and automatically powers on, when turning on your TV or audio source.
The 21 mm ultra-light weight soft dome tweeter is extremely compact, but retains a large membrane area, which ensures that it will reach deep down into the mid-range frequency areas without any break up or drop off’s. The strong neodymium magnet delivers high power handling and a high sensitivity to the soft dome tweeter, thereby bringing detail, accuracy and speed to the high frequencies.
DALI KATCH ONE Specifications:
|Frequency Range (+/-3 dB) [Hz]
||46 - 25,000
|Maximum SPL [dB]
|Crossover Frequency [Hz]
||250 / 2500
|High frequency driver, Quantity
||2 x 21 mm
|High frequency driver, Diaphragm type
||Soft Textile Dome
|Low frequency driver, Quantity
||4 x 3.5"
|Low frequency driver, Diaphragm type
||Aluminium Cone With Cloth Cap
|Low frequency passive driver, Quantity
||4 x 4.5"
|Low frequency passive driver, Diaphragm type
||Passive Radiators (4 pcs)
|Max. Amplifier Power Output [RMS watt]
||4 x 50
||Fully digital Class-D amplifiers
2 x Optical (TosLink)
3.5 mm Mini Jack
USB Charge Output (5V/1A)
||Bluetooth™ 4.0 AAC & Apt-X
Shelf or stand
Centre / Soundbar
||Auto Source Select
Dual Sound Mode (Wide/Focus)
Standby (Auto Power) Off
|Standby Power Consumption [W]
||<0,5 (Mains Adapter)
|Dimensions (HxWxD) [mm]
||164 x 860 x 69
||Mains Cable (2.0 m)
Wall Bracket (Leather Mount)
Quick Start Guide
