Description
Gold Note's P-1000 is an innovative Class-A line preamplifier powered by a new proprietary Six Gain Stage design and with Relays volume control and is made for real music lovers. P-1000 belongs to a new era of electronics where performance is combined with technology to offer the best possible musical experience: tradition and innovation meet to create a unique preamplifier with crystal clear sound. The preamplifier it’s easy to control with its large colour display showing all possible functions: it’s as easy as it gets, all the settings can be found on the display allowing quick and precise fine adjustments. Completing the 1000 series of Gold Note Hifi electronics, P-1000 is powered by a Triple Linear Transformer power supply and features 10 independent stereo inputs. Advanced functions paired with high-quality materials and an exquisite Italian product design turn P-1000 into a luxury solid state amplifier capable of top-class performances.
Featuring a Triple Linear Transformer power supply and 10 independent stereo inputs, 5 fully balanced XLR, 5 RCA (optionally even a digital input is available on demand). The preamplifier offers a large amount of functions: Mono/Stereo selection, Left/Right channel swap, Absolute Phase swap, Booster technology and fine Balance tuning. To perfectly reproduce even old recordings, the preamplifier can in fact be set into Mono or Stereo mode. It also allows to swap the Left & Right channels to allow the reproduction of inverted recordings as well as the absolute phase swap from 0° to 180°.
Specifications:
| FREQUENCY RESPONSE |
2Hz – 200KHz @ ± 3dB |
|---|---|
| THD (TOTAL HARMONIC DISTORTION) |
<0.001% @ 1kHz |
| GAIN |
+20dB |
| SIGNAL TO NOISE RATIO |
-120dB |
| CHANNEL SEPARATION |
>118dB |
| CHANNEL LEFT/RIGHT |
selectable swap |
| MONO/STEREO |
selectable |
| ABSOLUTE PHASE |
0°/180° |
| BOOSTER |
3 adjustable levels (by-passable/off) |
| ANALOGUE INPUTS |
5 Stereo RCA |
| INPUT LEVEL |
Up to 10Vrms on RCA |
| DIGITAL INPUT (OPTIONAL) |
TOS or Coax 24/192kH |
| INPUT IMPEDANCE |
100kΩ XLR & RCA |
| AUDIO OUTPUTS |
1 Stereo RCA unbalanced |
| OUTPUT LEVEL |
Up to 16Vrms on XLR & 8Vrms on RCA max. |
| VOLUME |
100 steps |
| OUTPUT IMPEDANCE |
<10Ω XLR & RCA |
| POWER SUPPLY |
Ultra Linear 3 transformers |
| REMOTE CONTROL |
Included |
| DIMENSIONS |
430mm W 135mm H 375mm D |
| WEIGHT |
11 Kg net |
| FINISHES |
Brushed Aluminium Black or Silver |
| UPGRADES |
TUBE-1006/1012: Class-A 6/12 Tubes output stages with Dual Mono/inductive tube power supply |
