Martin Logan Illusion ESL C34A Center Channel Speaker
Martin Logan Illusion ESL C34A Center Channel Speaker
Martin Logan does not permit this product to be ordered via an online shopping cart. Please contact us by phone or email for more information or to order. Thank you very much.
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
The ultimate performance floorstanding center channel loudspeaker that blurs the lines between performance and reality by combining the dynamics of a 34-inch wide XStat CLS electrostatic transducer with the detailed imaging capability of Folded Motion XT tweeters, four 6.5-inch PoweredForce Forward™ woofers powered by a 250-watt Class-D amplifier, and controlled by a 24-Bit Vojtko™ DSP Engine and ARC™ (Anthem Room Correction).
Timbre-matched to our flagship Masterpiece Series speakers to create a white-knuckle home theatre experience of skidding car chases, blitzing battle scenes, or even intimately whispered dialogue within a seamlessly coherent surround-sound environment, making the Illusion ESL C34A the perfect center of your Masterpiece home theatre.
Finish Options:
Gloss Black Dark Cherry Walnut
Premium Finish Options. Please contact us.
Rosso Fuoco Cordoba Red Deep Sea Blue Basalt Black
(Gloss Red) (Gloss Metallic Maroon) (Gloss Metallic Blue) (Gloss Metallic Black)
Meteor Grey Desert Silver Arctic Silver
(Gloss Metallic Silver, Dark) (Gloss Metallic Silver, Tan tint) (Gloss Metallic Silver, Light)
Specifications:
|
Horizontal Dispersion |
30° |
|
High Frequency Transducer |
Two 1.25" x 2.4" (3.2cm x 6.1cm) Folded Motion XT Transducers with 4.5" x 2.75" (11.4cm x 7cm) diaphragm. |
|
Mid Frequency Transducer |
Patented CLS™ XStat™ electrostatic transducer. » Panel Dimensions: 8" x 34.5" (20.3 x 87.6cm) » Radiating Area: 276 in² (1,778 cm²) |
|
Low Frequency Transducer |
Four 6.5" (16.5cm) cast basket, high excursion, rigid aluminum cone with extended throw drive assembly, non-resonance asymmetrical chamber format. |
|
Amplifier |
1x 250 watts/channel (4 ohms), 500 watts peak |
|
Room Correction (Bass Section) |
Anthem Room Correction (ARC) Ready (Sold Separately) |
|
Components |
Custom-wound audio transformer, air core coils, polypro- pylene capacitors. 24-bit DSP based preamplifier (used with woofer amplifier). |
|
Audio Controls |
Bass: ±10dB under 75Hz Mid-Bass: –2dB, 0dB, +2dB ARC Room EQ: On, Off |
|
Signal Inputs |
WBT-0703Cu nextgen™ 5-way binding posts feature a filigree signal conductor made from gold plated, nickel free, non- ferromagnetic, pure copper for high conductivity and fully insulated. Free from eddy current effects. |
|
Inputs |
AC Power, RJ45 (for ARC), mini USB (for ARC) |
|
Power Draw |
Max: 300W per channel Standby: <1W per channel |
