All Motion Series On Sale While Supplies Last.
Please CALL Us For Pricing on Packages/Bundles.
Martin Logan does not permit this product to be ordered via an online shopping cart. Please contact us by phone or email for more information or to order. Thank you very much.
The Martin Logan Motion 30i delivers the classic soundstage of the Motion Series from a newly designed enclosure enhanced by the slightest of modifications, including the drive-stabilizing dust cap design and stiffened motor suspension.
Frequency Response: 65–25,000 Hz ±3dB
Recommended Amplifier Power: 20—200 watts per channel
Horizontal Dispersion: 80°
Vertical Dispersion: 80°
Sensitivity: 91 dB/2.83 volts/meter
Impedance: 4 Ohms Compatible with 4, 6, or 8 Ohm rated amplifiers.
Crossover Frequency: 400 & 2,600 Hz
High Frequency Transducer: 1" × 1.4" (2.6cm × 3.6cm) Folded Motion Transducer with 5.25" × 1.75" (13.3cm × 4.4cm) diaphragm
Low Frequency Transducer: Two 5.5” (14cm) aluminum cone with cast polymer basket. Non-resonant asymmetrical chamber format. Rigid structured dust cap to reduce cone break-up modes.
Components: Custom air core coil and low DCR steel laminate inductors. Polyester film capacitors in series and low DF electrolytic capacitors in parallel. Overall system thermal/current protection.
Inputs: Custom 5-way tool-less binding posts
Weight: 18 lbs. (8.2 kg)
Dimensions: 6.9" x 16.5" x 10.5 "(17.5cm x 42cm x 26.6cm)
