Starting with high quality Lundahl™ transformers, surrounded by a specialized mu-metal shielding, listeners can be assured that every detail in a complex array of notes is reproduced with utter purity, with freedom from internal and external sources of interference. These two items combined make the ST-70 transformer one of the quietest, most revealing transformers.
Featuring dual mono design, the ST-70 provides discrete circuitry for each channel, resulting in the elimination of crosstalk and possible distortions. This results in cleaner, clearer reproduction with substantially increased stereo imaging.
Technical data Configuration A:
Recommended cartridge impedance 5-50 Ω
Gain 24 dB at 1 kHz
Frequency response 10 Hz - 100 kHz ± 1 dB
Recommended load 47 KΩ // 200 pF
Technical data Configuration B:
Recommended cartridge impedance < 10 Ω
Gain 30 dB at 1 kHz
Frequency response 10 Hz - 80 kHz ± 1 dB
Recommended load 47 kΩ / 200 pF
Dimensions and weight
Dimensions: 58 mm(W) x 135 mm(H) x 150 mm(D)
Weight: 1.233 kg
