Martin Logan Motion XTW6 In Wall Speaker
Martin Logan Motion XTW6 In Wall Speaker
Martin Logan does not permit this product to be ordered via an online shopping cart. Please contact us by phone or email for more information or to order. Thank you very much.
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
The Martin Logan Motion XTW6 offers incredible accuracy, clarity and more controlled dispersion. With an 80° x 30° tweeter dispersion pattern, the XTW6 directs and focuses sound into the sweet spot of the room without letting it bleed into other areas of the room. This can be highly effective, especially in rooms with open floor plans or large windows, etc. The XTW6 takes one of the most popular styles of in-wall speaker to a new level of performance and features the FMT XT and a 6.5” Kevlar woofer (with Nomex backer).
NOTE: PRICED PER EACH
Technical Specifications:
|
Tweeter Dispersion (horizontal x vertical) |
80 x 30 degrees |
|
Recommended Amplifier Power |
Range 50–200 Watts |
|
Amplifier Power |
Range 50–200 Watts |
|
High Frequency Driver |
FMT Transducer 1.27” x 2.4” (3.22cm x 6.09cm) Opening 4.5” x 2.75” (11.43cm x 6.98cm) Diaphragm |
|
Crossover Frequency |
2,460 Hz |
|
Crossover Type |
2 way |
|
Driver Configuration |
1 x 1.27” x 2.75” FMT, 1 x 6.5” Woofers |
|
Woofer Specifications |
One 6.5” (16.51 cm) cast aluminum basket, black Kevlar with Nomex backer cone, Open back chamber format. Concave dust cap. |
|
Cabinet Material |
Black w/ White Paintable Grill |
|
Connector |
Push style |
|
Components |
Custom air core coil inductors, polyester film capacitors in series and low DF electrolytic capacitors FMT thermal/current protection. |
|
Max Power Handling |
100 Watts |
|
Required Wall Opening (includes tolerance) |
7” x 10.13” (17.9 x 25.9cm |
|
Projection From Wall Surface |
0.31” (0.79cm) |
|
Depth Behind Wall Surface |
3.43” (8.72cm) |
