Aune Audio
Aune Audio S9c Pro Headphone Amplifier DAC IN STOCK
Aune Audio S9c Pro Headphone Amplifier DAC IN STOCK
Regular price
$999.00
Regular price
Sale price
$999.00
Unit price
per
Sale
Featured
Sold out
Shipping calculated at checkout.
Couldn't load pickup availability
Lighting fast delivery in Canada
Canadian Warranty
Customer Experience
Description
SILVER IN STOCK. Without Bluetooth.
Other Products Usually Ship Within 2 Days.
No Discounts Possible With This Product.
Affirm Cannot Be Used With This Product.
The S9c Pro is Aune Audio's new generation of DAC with headphone amp. Taking two years to develop, this product features of full clock synchronization, the 2nd gen of ultra-low-jitter PLL core, the 10M clock input, the specially designed filter modes with our own algorithm, Dual-ES9068A, and the fully-discrete headphone amp whose output power is as high as 5W.
| SPECIFICATIONS: | |
|---|---|
| Product type | DAC Headphone amplifier |
| Inputs | 1* USB-B 1* AES/EBU 1* Coaxial 1* Optical Toslink 1* BNC 10Mhz connector for external clock Bluetooth |
| Outputs | 1* Single-ended stereo RCA 1* Balanced stereo XLR 1* Balanced XLR 4 pins headphone output 1* Single-ended Jack 6.35mm headphone output 1* Balanced Jack 4.4mm headphone output |
| USB interface | XMOS |
| DAC chip | 2* ES9068AS |
| Supported sampling rates | USB : PCM up to 32bit 768kHz / Native DSD up to DSD512 / MQA 16x Optical / Coaxial / AES : PCM up to 24bit 192kHz |
| Supported Bluetooth codecs | AAC, SBC, aptX, aptX HD, LDAC |
| Preamplifier output power | 5W |
| HEADPHONE OUT | ||||
|---|---|---|---|---|
| Impedance | 32Ω | 100Ω | 300Ω | 600Ω |
| Single-ended Jack 6.35mm headphone output power | 1445mW | 490mW | 169mW | 84mW |
| Balanced Jack 4.4mm and XLR 4 pins headphone outputs power | 5780mW | 1960mW | 672mW | 336mW |
| Noise floor | 7.71uV | |||
| THD+N | 0.00058% | |||
| Impedance | 1 Ohm | |||
| LINE OUT | |
|---|---|
| Output level | 2.2Vrms |
| Noise floor | 2.04uV |
| Dynamic range | 122dB |
| THD+N | 0.00029% |
| XLR OUT | |
|---|---|
| Output level | 4.99Vrms |
| Noise floor | 4.07uV |
| Dynamic range | 122dB |
| THD+N | 0.00022% |
| GENERAL | |
|---|---|
| Supply voltage | 220-240V AC |
| Color | Black |
| Weight | 3.1kg |
| Dimensions | 288*211*63mm |
| Package | 1* Aune S9c Pro 1* Power cable 1* USB-A to USB-B cable 1* Bluetooth antenna 1* Jack 3.5mm to Jack 6.35mm adapter |
