Cayin CS-6LA Tube Preamplifier
Cayin CS-6LA Tube Preamplifier
Usually ships in 1-2 days.
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
The new Cayin CS-6LA preamplifier features dual pairs of stereo outputs, allowing for bi-amp configurations. To ensure reliable voltage supply rectification for the linear amplification, it utilises two NOS US RCA 22DE4 rectifier tubes in conjunction with four Russian 12AU7EH tubes. This combination contributes to a sound presentation characterised by tranquility and fluidity.
Cayin maintains its commitment to excellence by incorporating premium components into the CS-6LA. American multicap coupling capacitors and Japanese TAKMAN carbon film resistors are carefully selected based on their tonal characteristics, enhancing the overall performance of the amplifier. The CS-6LA is equipped with a generously sized power transformer and chokes, promoting optimal dynamics and sound stability. The high-quality aluminium front plate of the CS-6LA exhibits excellent oxidation resistance and minimal surface photosensitivity.
- The new design SC-6LA deploys advanced vacuum tubes, coupling capacitor, carbon film resistor and a variety of high-class components. Effectively improved performance and audio quality. Collocated with 9084D MK2, creates the evolutionary home audio system concept.
- Constructed linear amplifier circuit with FOUR Electro-Harmonix 12AU7EH Preamp Tubes.
- Advanced rectifying circuit with TWO RCA 22DE4 Rectifiers.
- Deploys Multicap Coupling Capacitors & Takman Carbon Film Resistors.
- Designed for 15dB gain.
- Customized EI-Core Power Transformers.
Specifications:
Output voltage: 2V (22V Max)
Harmonic distortion: 0.4% (1kHz)
Power: 45W
Signal to noise ratio: 95dB
Gain: 15dB (1kHz)
Vacuum tube: 12AU7(EH) x 4, 22ED4 x 2
