The new Cayin HA-3A is a compact, high power tube headphone amp. It is beautifully designed with all black or silver gloss faceplate, removable tube cage and vu-meters with white backlighting. Hand built featuring point to point wiring, with practical features to extend the life of the tubes and the amp, like 60 second start up delay and tube preheating.
Perfect for someone with multiple headphones, the HA-3A features 3 outputs: 6.35mm SE, 4.4mm low power / low noise for earphones and a XLR high power output for full size headphones. There are three switches on the front panel to select the input, headphone output and the impedance range: Low / Mid / High
Cayin engineers have optimized HA-3A’s output to handle the headphone loading according to three headphone impedance settings:
Low: 8Ω ~ 64Ω
Medium: 65Ω ~ 250Ω
High: 251Ω ~ 600Ω
The chassis and transformer pots are treated by proprietary 14 rounds of crafting process composed of scratch, spray, sanding and baking.
The high gloss final finishing endows a refined and delicate texture as well as protecting the amplifier during years of long service.
A set of three 39x18mm XL shock-absorbing aluminum foot pads provide a firm and stable amplifier base for any hard flat surface.
Specifications:
- STD unbalanced output: 400mW+400mW(L); 600mW+600mW(M): 700mW+700mW(H)
- 4.4BAL balanced output: 230mW+230mW(L); 350mW+350mW(M); 400mW+400mW(H)
- 4PIN BAL balanced output: 600mW+600mW(L): 750mW+750mW(M): 850mW+850mw(H)
- Frequency response: 18Hz~30kHz±3dB
- Total harmonic distortion: 0.2%
- Signal-to-noise ratio: 100dB (A-weighted)
- Headphone impedance matching: L: 8~64Ω; M: 65~250Ω; H: 251~600Ω
- Headphone output socket: 6.35mm SE; 4.4mm BAL; 4PIN XLR BAL
- Input terminal: XLR, RCA
- Vacuum tubes used: JJ 12AU7/ECC82×2, JJ 6V6S×2, RCA22DE4×1
- Includes 1m power cable
- Ships with tubes installed, foam protection inside black finish metal tube protection cover
- Volume: 31 cm×26 cm×17 cm
- Net weight: 12KG
