Dynavector

Dynavector DV-20X2A Phono Cartridge

Dynavector DV-20X2A Phono Cartridge

Usually Ship Within 2 Days.

Regular price $1,550.00
Regular price Sale price $1,550.00
Sale Featured Sold out
Free Express Shipping In Canada
Dynavector DV20X2A

Free Express Shipping In Canada

Canadian Warranty

Professional Customer Experience

View full details

Description

Dynavector's DV-20X has a solid aluminum alloy body and a rigid magnet construction similar to XX-2MKII. Both high and low versions of their 20X2 are available ensure for the optimum end result. The high output model is well suited to valve preamplifiers or electronics that only offer MM inputs whilst the low output version offers superb performance when combined with dedicated moving coil inputs. The cantilever is a 6mm length of hard aluminum pipe with a Micro-Ridge stylus. The magnetic flux damping and softened magnetism along with powerful neodymium magnets gives the 20X2H a healthy 2.8 mV output - suitable for most MM inputs. The 20X2L has an output of 0.3 mV ideal for most MC phono stages.

Specifications:

  • Type: High/Low output moving coil cartridge with flux damper and softened magnetism
  • Output Voltage: 2.8mV / 0.3mV (at 1KHz, 5cm/sec.)
  • Channel Separation: 25 dB (at 1KHz)
  • Channel Balance: 1.0 dB (at 1KHz)
  • Frequency Response: 20 - 20,000Hz (± 1dB)
  • Compliance: 12 mm/N
  • Tracking Force: 1.8 - 2.2 g
  • Impedance: 150 ohms / 5 ohms
  • Recommended Load Impedance: > 1,000 ohms / > 30 ohms
  • Cantilever: 6mm length, hard aluminium pipe
  • Stylus Tip: Micro Ridge Nude diamond
  • Weight: 9.2 g
