Description
Dynavector's DV 507 MKII tonearm delivers impeccable trackability, effortlessly gliding over even the most challenging of warped recordings. Bid farewell to skips and interruptions, and let your vinyl collection be heard as it was meant to be. This tonearm unveils an unparalleled level of resolution and musical detailing that will leave you spellbound. Rediscover your music collection with a depth and richness that transcends your expectations. At the heart of the DV 507 MKII's prowess is its cutting-edge bi-axis inertia control system. Whether you're using a high-end cartridge or a classic favorite, this tonearm boasts unmatched accuracy in tracing the music signal grooves etched into your cherished vinyl records. Experience your music with unprecedented precision, where every note, every subtlety is faithfully brought to life.
Specifications:
| Type | Bi-Axis inertia controlled Dynamic and Eddy Current Damping Dynamic Balance type tone arm |
| Overall length | 306mm. With head shell: max 326 mm |
| Effective length | 241mm (i.e. tonearm pivot point to cartridge stylus point) |
| Overhang | 15mm |
| Offset angle | 21.5 degree |
| Height | 59mm lifts up to 92mm |
| Height adjustment range | 39mm-72mm at sub arm center |
| Depth | 36mm without connecting cable |
| Optimum cartridge weight | 15-35 g, including headshell |
| Horizontal tracking angle error | -1.1 degree - +2.2 degree , 0 degree at inner band of record, 2.2 degree at outside |
| Tracking force adjustment range | 0-38 g by 0.2 g step |
| Sensitivity | Horizontal:less than 50 mgrams, Vertical:less than 40 mgrams |
| Net weight | 1,380 g |
| Output connection | 5P connector |
| Headshell connection | EIA standards 4 Pin connector |
| Accessary | low resistance (0.046 ohms/m, 54pF/m) high quality arm cable, milled aluminium headshell weight 15.4 g. mounting template for the arm overhang guage for the headshell |
