Gold Note Tube-1012 Tube Output Stage
Gold Note Tube-1012 Tube Output Stage
Initial Stock Due In Late May To Early June.
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
Gold Note's TUBE-1012 easy to connect, easy to use. They are capable of great control and definition providing outstanding realism in recreating the musical event. It's the best way to improve the Gold Note electronics even further to reach a whole new level of performance through the Class A 12 or 6 valve output stages. Our sources and amplification are solid state designs. But if you prefer the sound of the tubes and want to bring your system to its very top performance, the TUBE-1012 is the way to go. Connect them to your Gold Note electronics and listen – you’ll hear Solid State and Tubes playing in perfect synergy to deliver the best performance, wonderfully natural and musical, for a truly High-End listening experience. Our proprietary Totem-Pole Output Stage design, with six independent audio stages per single tube, guarantees ultra-wide bandwidth response and ultra-low distortion to deliver the purest audio signal ever.
Specifications:
| TUBE-1012 |
Totem-Pole Output Stage design |
|---|---|
| MAX INPUT |
8Vrms linear |
| MAX OUTPUT |
20Vrms @ XLR & 10Vrms @ RCA |
| OUTPUT IMPEDANCE |
<600Ω |
| INPUT SENSITIVITY |
4Vrms |
| RECOMMENDED LOAD |
>5KΩ |
| TUBES |
TUBE-1012: 6n1p x 12 |
| TRANSFORMERS |
No coupling transformers on the IN/OUT |
| GAIN |
+3,5 dB |
| POWER ABSORPTION |
TUBE-1012: 80W |
| POWER SUPPLY |
100-120V / 220-240V, 50/60Hz |
| DIMENSIONS |
430mm W 135mm H 370mm D |
| WEIGHT |
TUBE-1012: 16Kg net – 21Kg boxed |
| FINISHES |
Brushed Aluminium Black, Silver or Gold |
