Description
The new Lumin S2 brings X1 Performance from the X1 to a single chassis
Main features:
- Award-winning X1 architecture
- X1 Dual ES9038PRO SABRE DAC featuring dual-mono operation
- X1 analogue output stage including Lundahl output transformers
- Dual-toroid power supply now adapted and shielded for internal housing
- NEW digital inputs open up the unique LUMIN ES9038PRO DAC implementation to external digital sources
- Seamless streaming through TIDAL, Qobuz, Spotify Connect, KKBOX, Amazon Music, AirPlay, Roon Ready, JPlay, and Audirvana and more... all managed via the LUMIN app for iOS and Android.
- LEEDH Processing Lossless Volume Control
Specifications:
-
NETWORK PLAYBACK:
- Up to DSD512
- Up to 384 kHz, 16–32-bit, Stereo
- MQA Full Decoding
-
UPSAMPLING RATES & BIT DEPTHS:
- DSD256 upsampling option for all files
- PCM 384kHz upsampling option for all files
-
DIGITAL INPUT:
-
OPTICAL/COAXIAL:
- PCM 44.1 kHz–192 kHz, 16–24-bit
- DSD64 (DoP64, DSD over PCM)
-
-
DIGITAL OUTPUT:
-
USB:
- Native DSD512 support
- PCM 44.1–384 kHz, 16–32-bit, Stereo
-
-
ANALOG OUTPUT:
- Dual ESS SABRE32 ES9038Pro DAC chips
- Fully balanced layout with high-quality components
- Output connectors coupled with dual LUNDAHL LL7401 output transformers
- Femto Clock System with precision FPGA distribution
-
OPTICAL NETWORK:
- Industry-standard Gigabit SFP
- 1000Base-T Gigabit Ethernet
- Adapter may be needed for your particular switch/cables
- Use simultaneously with RJ45 (e.g. connect one to router and one to LUMIN N1 or NAS)
-
POWER SUPPLY:
- Internal dual-toroid
- Separate digital & analogue circuitry
- Low-noise linear regulator
-
PHYSICAL:
-
FINISH:
- Black anodised aluminium
- Raw aluminium
DIMENSIONS:
- 350mm (W), 380mm (D), 107mm (H), 8kg
-
SPECIFICATION FOR ALL CURRENT-GEN LUMIN STREAMERS:
-
STREAMING PROTOCOL:
- UPnP AV protocol with audio streaming extension (OpenHome)
- Roon Ready
- Qobuz Connect
- TIDAL Connect
- Spotify Connect
- Flac lossless Radio stations
- Plāys with Audirvāna
- JPLAY Certified
- AirPlay-compatible
- QPlay-compatible for QQMusic
- Gapless Playback
- On-Device Playlist
-
APP FEATURES:
- Native support for TIDAL, MQA, Qobuz and TuneIn Radio.
- Tidal MAX and MQA icons to identify high-res music
- Qobuz high-res icons to identify high-res music
- Volume control
- High-resolution artwork
- Artwork caching
- Search
- Multiple tag handling
- Composer tag support
- Album-grouping in playlist
- Automatic internet links to artists/album/songs
- Saving and restoring of playlists (including Tidal and Qobuz)
-
SUPPORTED AUDIO FILE FORMATS:
- DSD Lossless: DSF (DSD), DIFF (DSD), DoP (DSD)
- PCM Lossless: FLAC, Apple Lossless (ALAC), WAV, AIFF
- Compressed (lossy) Audio: MP3
- MQA
-
INPUT:
- Gigabit Ethernet Network (1000BASE-T) RJ45
- Shared USB port can also be used for storage, flash drive, USB hard disk (Single-partition FAT32, exFAT and NTFS only)
-
ANALOGUE AUDIO OUTPUTS:
- XLR balanced, 6Vrms, pin 2 Hot
- RCA unbalanced, 3Vrms
-
SUPPORTED CONTROL DEVICES:
- Apple devices. iOS 15.0 or later
- Android devices. Android 6.0 (Marshmallow) or later required
- Apple Silicon. macOS 15 or later. (Download the iOS App from the iOS App Store)
- Chromebook. Google Play Store required.
-
OTHER:
- Leedh Processing lossless digital volume control
- MQA QRONO d2a filters available for all PCM music (excluding via AirPlay)
- Programme of Continuous Development – Firmware-upgradable for further features and enhancements
