The MP-60 is equipped with all the advanced technologies for which Lyngdorf Audio is known, including the renowned room correction system RoomPerfect and the unsurpassed quality in digital signal processing. Together with the Steinway Lyngdorf version, the P300, the MP-60 is developed at the group headquarters in Skive, Denmark.
The MP-60 features decoding and balanced outputs for 16 audio channels, with extraordinarily easy installation and daily use. With 8 HDMI inputs and 3 outputs (one being HDBaseT), this new masterpiece from Lyngdorf Audio now supports the HDMI 2.1 feature eARC, Dynamic Lip-Sync and QMS (Quick Media Switching) as well as the latest decoding and post-processing formats.
Now with full 16 channel decoding, the MP-60 offers full support of the immersive surround formats DOLBY ATMOS®, DTS:X® PRO and AURO-3D®, and it delivers a surround sound experience that outmatches anything in and above its class. Allowing a video throughput of up to 18 Gbps, the MP-60 now supports the full 4K 60Hz video stream including the passing of HDR or Dolby Vision information.
eARC will allow for a full Dolby Atmos audio bitstream being returned to the processor from the television, ensuring full audio quality from the TV’s built-in media players. The MP-60 of course also supports the pass-through of the new HDR format for streaming video: HLG (Hybrid Log Gamma).
The Lyngdorf Remote Application automatically discovers the MP-60 connected to your local network, and you will be able to adjust all the basic functions like input selection and volume level from your handheld device. The built-in media player can be controlled directly, and you can access music files stored on pen drives connected to the Lyngdorf MP-60 as well as search all files stored on your local hard drives. Swiping left and right gives you access to cover art as well as informing you of the signal resolution.
The Lyngdorf Remote Application is available for free download from both IOS and Android.
Decoding: Dolby Atmos®, Dolby Digital EX & Plus, Dolby TrueHD, DTS:X PRO, DTS ES Discrete 6.1, DTS ES Matrix 6.1, DTS 96/24, DTS-HD High Res. Audio, DTS-HD Master Audio, AURO 3D®, 16 native channels
Post processing options: Dolby Surround, AURO-MATIC®, DTS Virtual:X, DTS Neural:X
Audio inputs: 8 x HDMI (≤192kHz/24bit), 1 x AES/EBU S/P-DIF input (≤192kHz/24bit), 3 x S/P-DIF coaxial inputs (≤192kHz/24bit), 4 x S/P-DIF optical inputs (≤96Hz/24bit), 1 x USB audio input (≤192kHz/32bit), 1 x microphone input (XLR) for RoomPerfect
Audio outputs: 16 x XLR analog outputs (5.0 Vrms), 1 x SPDIF coax digital ZONE output (Fix 96kHz/24bit)
Audio specifications: Frequency response: ±0,5dB from 20 to 20,000 Hz, Total harmonic distortion: 0.005% max from 20 to 20,000 Hz
EQ: RoomPerfect, Subwoofer level assistant, 32 x adjustable voicings holding ≤8 shelving, high/low pass or parametric filters with adjustable gain and Q
Media player: Internet radio (vTuner), Airplay, Spotify Connect, Roon Endpoint (awaiting certification), DLNA Support of FAT32 based media storage.
Video inputs: 8 x HDMI (2.0b – HDCP 2.2), accepts 3D 30Hz, 4K 60Hz (18 Gbps), accepts HDR, Dolby Vision and HLG
Video outputs: 2 x HDMI (HDCP 2.2), 1 x HDBaseT
Video scaling: Upscaling of all video to 4K ultra high definition, no downscaling of 4K video
Control interfaces: 1 x DB9 RS232 connector, 2 x IR sensor inputs, 1 x IR output (loop from one of the sensor inputs), 1 x trigger input, 4 x trigger outputs, 1 x RJ45 ethernet LAN connector, 2 x USB A connectors, 1 x SD card slot , (Backup – storage for system software and settings)
Accessories included: RoomPerfect microphone, Microphone stand, Microphone cable, RF remote control
Optional module: 16 channel DCI-compliant digital AES/EBU input for movie servers (supports up to 32bit/192kHz), 16 channel digital AES/EBU speaker output channels (always 24bit, 48kHz or 96kHz. Selectable), 16 channel AES67 digital AES/EBU speaker output channels (supports up to 32bit/192kHz input, output is always 24bit/48kHz)
Placement options: Rack mount and freestanding
Dimensions (H x W x D): 14.7 x 45.0 x 37.0 cm, 5.8 x 17.7 x 14.6 in
Weight: 9 kg / 19 lbs
