NAD

NAD C 298 Amplifier

NAD C 298 Amplifier

Regular price $3,399.00
Regular price Sale price $3,399.00
Sale Featured Sold out
Free Express Shipping In Canada

Free Express Shipping In Canada

Canadian Warranty

Professional Customer Experience

View full details

Description



The new NAD C298 features the the amazing new Purifi Eigentakt™ (self-clocking) technology, recently introduced to the world in the EISA Award winning Masters M33, available to a wider audience with the very affordable C 298. We are thrilled to provide this unprecedented level of performance. In short, a perfect companion for the C 658 BluOS Streaming DAC pre-amp.

Features:

  • 185W x 2 Rated Output Power into 8 Ohms
  • 340W x 2 Rated Output Power into 4 Ohms
  • Stereo Dynamic Power 260/490/570W @ 8/4/2 Ohms
  • 620W x 1 Rated Output into 8 Ohms Bridge Mode
  • Mono Dynamic Power 1000/1100W @ 8/4 Ohms
  • Purifi Eigentakt Amplifier Technology
  • Balanced Line Inputs
  • Single-Ended Line Inputs
  • Input Level Control
  • Line Output for Daisy Chaining
  • 12V Trigger In/Out
  • Auto Turn-on with Selectable Threshold
  • IR In/Out
  • Ground Lug
  • Detachable AC Power Cord

Specifications:

ANALOG AUDIO INPUT/LINE OUT
  • THD (20 Hz – 20 kHz)
  • <0.0005 % at 2V out
  • Signal-to-Noise Ratio
  • >120 dB (IHF; 20 Hz – 20 kHz, ref. 2V out)
  • Channel separation
  • >110 dB (1 kHz)
    >100 dB (10 kHz)
  • Input impedance (R and C)
  • Single-ended: 56 kohms + 280 pF
    Balanced: 56 kohms +280 pF
  • Maximum input signal
  • >7.0 Vrms (ref. 0.1 % THD)
  • Output impedance
  • 390 ohms
  • Frequency response
  • ±0.1 dB (20 Hz – 20 kHz)
  • Maximum voltage output -IHF load
  • ≥>7.0 V (ref. 0.1 % THD)
ANALOG AUDIO INPUT/SPEAKER OUT
  • Rated output power into 8 Ohms and 4 ohms (Stereo mode, ref. 20 Hz-20 kHz at
    rated THD, both channels driven)
  • 185 W at 8 ohms
    340 W at 4 ohms
  • Rated output power into 8 Ohms
    (Bridge mode, ref. 20 Hz-20 kHz
    at rated THD, both channels driven)
  • 620 W at 8 ohms
  • THD (20 Hz – 20 kHz)
  • <0.005 % (1 W to 185 W, 8 ohms and 4 ohms)
  • Signal-to-Noise Ratio
  • >98 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
    >120 dB (A-weighted, ref. 185 W out in 8 ohms)
  • Clipping power (Stereo mode, at 1 kHz 0.1 % THD)
  • >200 W
  • Clipping power (Bridge mode, at 1 kHz 0.1 % THD)
  • >690 W
  • IHF dynamic power (Stereo mode, at 1 kHz 1 % THD)
  • 8 ohms: 260 W
    4 ohms: 490 W
    2 ohms: 570 W
  • IHF dynamic power (Bridge mode, at 1 kHz 1 % THD)
  • 8 ohms: 1000 W
    4 ohms: 1100 W
  • Peak output current
  • >25 A (in 1 ohm, 1 ms)
  • Damping factor
  • >800 (ref. 8 ohms 20 Hz – 6.5 kHz)
  • Frequency response
  • ±0.2 dB (20 Hz – 20 kHz)
    -3 dB at 60 kHz
  • Channel separation
  • >100 dB (1 kHz)
    >80 dB (10 kHz)
  • Stereo Mode input sensitivity (for 185 W in 8 ohms)
  • Fixed Gain mode: 1.43 V
  • Stereo Mode Gain
  • Fixed Gain mode: 28.6 dB
  • Line In – Balanced and Single-ended
  • Variable Gain mode: 8.5 dB – 28.5 dB
  • Bridge Mode Sensitivity
  • Fixed Gain mode: 3.78 V for 620 W in 8 ohms
  • Line In – Balanced and Single-ended
  • Variable Gain mode at maximum: 1.41 V for 620 W in 8 ohms
  • Bridge Mode Gain
  • Fixed Gain mode: 25.4 dB
  • Line In – Balanced and Single-ended
  • Variable Gain mode: 14.5 dB – 34.5 dB
  • Standby power
  • <0.5 W
DIMENSION AND WEIGHT
  • Gross dimensions (W x H x D)
  • 435 x 120 x 390 mm (17 1/8 x 4 3/4 x 15 3/8 inches)
  • Net weight
  • 11.2 kg (24.7 lbs)
  • Shipping weight
  • 13.6 kg (30 lbs)
