NAD M33 V2 Integrated Amplifier COMING SOON
NAD M33 V2 Integrated Amplifier COMING SOON
Pre-Order. Stock Due In Mid October.
Regular price
$8,599.00
Regular price
Sale price
$8,599.00
Unit price
per
Sale
Featured
Sold out
Free Express Shipping In Canada
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
One of the most compelling aspects of the M33 V2 is its intuitive user experience. A seven-inch touchscreen colour display simplifies operation, while the built-in BluOS streaming platform offers seamless multi-room connectivity and Roon Ready integration. Support for Master Quality Authenticated (MQA) audio and over 25 premium and free music services—including Tidal, Qobuz, Amazon Music HD, and Spotify—make the M33 V2 a streaming integrated amplifier that puts an entire musical universe at your fingertips. Combine this with Apple AirPlay 2, Qualcomm aptX HD Bluetooth, and compatibility with local libraries, and your music streaming amplifier becomes a limitless gateway to sonic exploration.
FEATURES & DETAILS:
• BluOS Streaming DAC Amplifier
• Second-Generation HybridDigital Purifi Eigentakt™ Amplifier Technology
• Continuous Power: 200W into 8/4 Ohms
• Dynamic Power: 300W into 8 Ohms, 550W into 4 Ohms
• ESS Sabre ES 9039PRO DAC
• Dirac Live Room LE Correction
• Optional Dirac Live Full Bandwidth and Bass Control (licenses sold separately)
• Colour LCD touch display
• Supports Amazon Alexa
• AirPlay 2 Integration
• Supports Siri voice assistant via AirPlay 2
• Two-way Qualcomm aptX® HD Bluetooth
• Gigabit Ethernet
• Dual Band Wi-Fi 5 a/c/n
• HDMI eARC, USB Type A input
• MM/MC phono stage with infrasonic filter
• Line-level RCA inputs
• AES/EBU XLR input
• XLR balanced line input
• 2 x optical inputs
• 2 x coax inputs
• XLR balanced preamp output
• Stereo RCA preamp output
• Subwoofer outputs, with selectable crossover frequency
• High-current headphone amplifier
• 2 x MDC Slots for future expansion
• IR input
• 12V trigger in, 2x 12V trigger out
• Apps for iOS, Android, Mac OS, Windows
• Works with leading smart home systems, including Control4, Crestron, iPort, Josh.ai, KNX, Lutron, Nice, RTI , and URC
• Wide variety of premium music services supported in app, including Amazon Music HD, Spotify, Tidal, Qobuz, TuneIn, Napster, Deezer, and many others
Specifications:
AMPLIFIER SECTION
◦ Rated output power (ref. 20 Hz-20 kHz at rated THD, both channels driven)
◦ >200 W into 8 ohms >380 W into 4 ohms
◦ Rated output power, Bridge mode (ref. 20 Hz – 20 kHz at rated THD)
◦ >700 W into 8 ohms
◦ Input sensitivity
◦ 865 mV (ref. 200W 8 ohms, Volume maximum)
◦ THD (20 Hz – 20 kHz)
◦ TBD
◦ Signal-to-Noise ratio
◦ TBD
◦ Clipping power
◦ >210 W (0.1 % THD 1 kHz 8 ohms)
◦ IHF dynamic power
◦ 8 ohms: 260 W
4 ohms: 520 W
◦ Peak output current
◦ ≥25 A (in 1 ohm, 1 ms)
◦ Damping factor
◦ >800 (ref. 8 ohms, 20 Hz to 6.5 kHz)
◦ Frequency response
◦ ±0.2 dB (20 Hz -20 kHz)
-3 dB at 60 kHz
PREAMPLIFIER SPECIFICATIONS
LINE IN
• Input Impedance (r and c)
• 47kΩ/180pF
• Input Sensitivity
• 280mV (ref. 500mV out, Volume Maximum)
• Maximum input level 20Hz-20Khz
• 2 Vrms/8 Vrms (low sensitivity mode)
• Tone Controls
• Treble: ±6 dB at 10kHz Bass: ±6 dB at 100Hz
• Max Output Signal
• 4Vrms (ref. 0.1% THD)
PREOUT
• Maximum output level
• 3.9 Vrms (ref. 0.1% THD)
• Signal-to-Noise ratio
• >120 dB (A-weighted, ref. 2 V out)
• Output impedance
• 100 ohms
SUBOUT
• Maximum output level
• 1.1 Vrms (ref. 0.1 % THD 100Hz)
• Signal-to-Noise ratio
• >102 dB (20 Hz-20 kHz, ref. 1V out)
• THD+N
• <0.005 % (refer 1.1 V 20 Hz-200 Hz)
• Output impedance
• 680 ohms
PHONO
• Input sensitivity
• MM: 1.2 mV
MC: 100 µV
• Input impedance (R and C)
• MM: 56 kohms/100 pF
MC: 100 ohms/280 pF
• Signal to noise ratio (ref. 2 V Preout A-weighted)
• MM: >92 dB
MC: >76 dB
• THD+N (ref 2V Preout 1kHz)
• MM: <0.003 %
MC: <0.02 %
• RIAA response accuracy MM/MC
• ±0.2 dB 20 Hz -20 kHz
HEADPHONES
• Output Impedance
• 2.2ohms
• Output power
• >100 mW/32 ohms
BluOS SPECIFICATIONS
AUDIO
• Supported audio file format*
• MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS
• Supported high- resolution audio file format*
• FLAC, MQA, WAV, AIFF
• Sampling rate
• up to 192 kHz
• Bit depths
• 16 – 24
CONNECTIVITY
• Network connectivity
• Gigabit Ethernet RJ45
Wi-Fi 5
• Supported network file share protocol
• Server Message Block (SMB)
• USB
• 1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals
• Bluetooth quality
• Support for aptX® HD
• Bluetooth connectivity
• Two-Way (Receive and Headphone modes)
USER INTERFACE
• Supported operating system**
• Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions**
• Mobile Application
• Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops
• Front panel
• 7-inch full colour touch screen
• Remote control
• HTRM 2 remote control
SUPPORTED SERVICES
• Music Services & Internet Radio:
• 23+
Music Services/Internet Radio
• Integration partners***
• Control4, RTI, Crestron, URC, push, iPort, ELAN, Lutron, Roon, AirPlay 2
• Voice Control Integration***
• Skills and support for Amazon Alexa, Google Assistant and Apple’s Siri with corresponding enabled devices and App
POWER CONSUMPTION
• Auto Standby ON
• <0.5W
• Idle Power
• <40W
DIMENSIONS AND WEIGHT
• Dimensions WxHxD ****
• 435 x 133 x 396 mm (17 1/8 x 5 1/4 x 15 5/8 ”)
• Net Weight
• 9.7kg (21.4lb)
• Shipping Weight
• 18.4kg (40.6 lb)
• Shipping Size (W x H x D)
• 569 x 258 x 519 mm (22 13/32 x 20 7/16 x 10 5/32 ”)
