Parasound ZM12 12 Zone Power Amplifier
Parasound ZM12 12 Zone Power Amplifier
Usually ships within 2 days.
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
Parasound's ZM12 power amplifier is perfect or delivering music or voice across multiple rooms without taking up space. This amplifier packs twelve channels of powerful amplification into a compact 2U rack unit. It combines robust power with flexibility, making it ideal for home or commercial multi-room sound systems.
The ZM12 powers 12 channels across 6 zones, with Zone 1 at 120 W/ch into 8 Ω (150 W into 4/2 Ω) and Zones 2–6 at 60/100 W. A Class‑AB input stage feeds premium Class‑D modules that are stable at 2 Ω, while A/B speaker outputs per channel (24 total) and stereo/mono per‑zone switching simplify real‑world wiring. Integration is painless with per‑zone audio‑sensing and 12 V triggers plus a speaker‑level input for systems without pre‑outs.
Features & Specifications
- Universal amplifier for applications from 60 to 150 watts
- Zone 1 (channel 1&2) are higher power for more demanding applications
- 24 speaker connections (A and B outputs for all 12 channels)
- High current for stable operation at 2 Ohms
- Class AB input stage plus premium Class D power stage
- Independent audio sensing triggers, one for each zone
- 6 Independent 12 volt trigger inputs, one for each zone
- Looping 12 volt trigger outputs for each zone
- Master 12 volt trigger input to turn all zones on-off
- Speaker level input for expanding systems w/out pre out jacks
- Two bus inputs can be routed to any zone
- Bus loop output jacks for passing audio to another amp
- Summed Mono mode combines L and R for single speaker applications
- Separate level controls for all twelve channels
- Detachable speaker connectors accept up to 12 gauge wire
- Short circuit and overheat protection with front panel indicators
- 0.5 watt standby power consumption meets Energy Star & EU specs
- Compact 2U chassis
Specifications:
-
Power Output : Zone 1 (Channel 1–2)
120 watts x 2 @ 8Ω
150 watts x 2 @ 4Ω or 2ΩPower Output : Zone 2-6 (Channels 3–12)
60 watts x 10 @ 8Ω
100 watts x 10 @ 4Ω or 2Ω
Note: Power ratings are RMS, All Channels Driven (20 Hz – 20 kHz)Minimum Speaker Impedance:
A+B Outputs of a Single Channel: 2 Ω
Note: Continuous operation at this minimum impedance might require additional ventilation for the amplifier.Frequency Response:
20 Hz – 20 kHz, +0/-0.25 dB
5 Hz – 50 kHz, +0/-3 dBTotal Harmonic Distortion:
< 0.05 % at typical listening levels
< 1.0% at full powerInterchannel Crosstalk: 70 dB at 20 kHzTotal Gain: 29 dB (Level controls set to Maximum)S/N Ratio: >112 dB, input shorted, IHF A-weightedDC Trigger Requirements: +9 Vdc to +12 Vdc, 5 mAAudio Trigger Requirements: 2 mV audio signal
AC Power Requirement:
1550 Watts maximum
150 Watts typical (audio playing on all zones)
55 Watts idle (all zones on)
15 Watts idle (one zone on)
0.5 Watts standby
100-250 VAC 50/60 Hz (automatic)Dimensions:
Width: 17.25″ (437 mm)
Depth: 14.5″ (369 mm)
Depth, with cables: 16″ (406 mm)
Height, with feet: 4.15″ (105 mm)
Height, without feet: 3.5″ (89 mm)Weight:
Net: 21 lbs (9.5kg)
Shipping: 27 lbs (12.2kg)
