Woo Audio WA22 Gen 2 Headphone Amplifier

Woo Audio WA22 Gen 2 Headphone Amplifier

Regular price $3,860.00
Regular price Sale price $3,860.00
Sale Featured Sold out
Shipping calculated at checkout.
WA22 Gen 2

Lighting fast delivery in Canada

Canadian Warranty

Customer Experience

View full details

Description


Usually Ships Within 3 Days.





The Gen 2 WA22 includes improved sonic performance and a preamplifier feature for use with a Hi-Fi system. WA22 (2nd gen) is an all-tube design, fully balanced headphone amplifier and preamplifier. The advantage of a fully balanced system is improved channel separation, more precise soundstage, and imaging. Perfectly suited for the headphone enthusiast and experienced audiophiles seeking flexibility and purest sound.








Specifications:


  • Updated to 2nd generation in March 2018

  • Tubes: 6SN7 driver x 2, 6080 power x 2, 5U4G rectifier x 1

  • Polytetrafluoroethylene (PTFE) tube sockets

  • ALPS RK27 4-channel balanced smooth potentiometer

  • Fully-balanced design, Class-A

  • Power output: up to 1.5 watts per channel @32 Ohms [recommended for power demanding headphones]

  • Transformer-coupled, Point-to-Point wiring, Pseudo-dual power supply

  • Phase Splitter for use with unbalanced components

  • HI / LO impedance setting

  • XLR input x 1, RCA input x 1

  • Dual 3-pin XLR (left and right channel), 4-pin XLR and 1/4" (6.3mm) stereo headphone outputs

  • XLR balanced PREAMP output (<50 ohms)

  • Anodized aluminum chassis, available in black or silver

  • Self-biasing with compatible tubes

  • Dimensions: 7"(H), 12"(W), 10½"(D) amplifier 25 lbs.

  • Designed and assembled in New York, USA

  • Three-year limited warranty

  • AC power cord and audio cables are not included
