JL Audio

JL Audio E-Sub e112 Subwoofer

JL Audio E-Sub e112 Subwoofer

Regular price $4,150.00
Regular price Sale price $4,150.00
Sale Featured Sold out
Shipping calculated at checkout.
E-Sub e112

Lighting fast delivery in Canada

Canadian Warranty

Customer Experience

View full details

Description





JL Audio does not permit this product to be ordered via an online shopping cart. Please contact us by phone or email for more information or to order. Thank you.







The JL Audio E-Sub e112 Subwoofers deliver exceptional sound quality, power and value in a wide range of demanding applications. The extreme mounting depth of the E-Sub driver is very deliberate. It permits wide gaps to exist between the three suspension elements (the rubber surround and the dual spiders), imparting exceptional mechanical stability over the driver's full excursion range. This further improves linearity, reduces distortion and enhances long-term reliability.

Specifications:

Unbalanced Inputs Stereo or Mono (two RCA jacks)
Balanced Inputs N/A
Speaker/High-Level Inputs Stereo or Mono (removeable plug)
Input Grounding Isolated or Grounded
Input Modes N/A
Level Control Variable, from full mute to +15dB over reference gain
Filter Mode(s) Low-Pass
Filter Slope(s) 24 dB/octave
Filter Frequency Range 25 Hz - 130 Hz
Filter Defeat Function Yes
Polarity 0 or 180 degrees
Phase Variable, 0- 280 degrees, referenced to 80 Hz
Extreme Low Frequency (E.L.F.) Trim N/A
Line Outputs Stereo or Mono (two RCA jacks), High-Pass or Pass-Through
Output to Slave N/A
Calibration Mode N/A



Enclosure Type Sealed
Enclosure Finish Black Ash
Frequency Response (Anechoic) 22 - 118 Hz (±1.5dB)
-3 dB at 21 Hz / 120 Hz
-10 dB at 17 Hz / 153 Hz
Effective Piston Area (Sd) 84.4 sq in / 0.0545 sq m
Effective Displacement 235 cu in / 3.9 L
Amplifier Power 1500 W RMS short-term
Power Mode(s) Off, On or Automatic (Signal-Sensing)
Light Modes N/A
Width (W) 15.5 in / 394 mm
Height (H) 16.23 in / 412 mm
Depth (D) 18.39 in / 467 mm
Net Weight 73.5 lb / 33.3 kg
