Frequency Response
|
71–25,000 Hz ± 3 dB
|
|
Tweeter Dispersion (horizontal x vertical)
|
80° x 30°
|
|
Sensitivity
|
94 dB @ 2.83 volts/ meter
|
|
Impedance
|
4 ohms. Compatible with
4, 6, or 8 ohm rated amps.
|
|
High Frequency Driver
|
1.25 x 2.4 inch (3.2 x 6.1 cm)
Folded Motion XT Obsidian
transducer with 4.5 x 2.75 inch
(11.4 x 7 cm) diaphragm.
|
|
Crossover Frequency
|
2250 Hz
|
|
Tweeter Aiming
|
Rotatable tweeter for horizontal
or vertical installations
|
|
Low Frequency Driver
|
Two 5.25-inch (13.33 cm) black
unidirectional carbon fiber
multi-section cone with Nomex®
backer and cast aluminum
basket, sealed back chamber
format. Concave dust cap.
|
|
Passive Radiators
|
Two 6.5-inch (16.5 cm) black
unidirectional carbon fiber
multi-section cone with Nomex®
backer and cast aluminum
basket, sealed back chamber
format. Concave dust cap.
|
|
Components
|
Custom air core coil inductors,
polypropylene film capacitors,
and low DF electrolytic capacitors.
Thermal/current protection.
|
|
Suitable Amplifier Range
|
20–250 watts
|
|
Max Power Handling
|
125 watts
|
|
Binding Post Inputs
|
Push style (two sets for
easy installation)
|
|
Weight
|
25.5 lb (11.6 kg)
|
|
Dimensions (overall size)
|
31.13 x 10.6 x 4.09 inch
(790.82 x 269.2 x 103.93 mm)
|
|
Required Wall Opening (includes tolerance)
|
29.82 x 9.29 inch
(757 x 236 mm)
|
|
Projection From Wall Surface
|
0.31 inch
(7.8 mm)
|
|
Depth Behind Wall Surface
|
3.8 inch
(96.5 mm)
|
|
Optional Accessories
|
Pre-install bracket (PN: 5XWBRK)
|
