Clearaudio Balance Reference Phono Stage With Headphone
Clearaudio Balance Reference Phono Stage With Headphone
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
The new Clearaudio Balance Reference Phono stage is one device containing two full-fledged symmetrical phono preamplifiers as well as an excellent headphone amplifier.
The new balance reference phono was developed especially for the phono enthusiast, featuring completely independent phono inputs for connecting moving coil and moving magnet phono cartridges. It provides total freedom in selecting balanced (XLR) or single-ended (RCA) inputs and outputs with the total flexibility of adjusting the input impedance for most cartridges.
The sophisticated volume and input circuitry are accessible with the supplied REMOTE CONTROL. The high-performance design provides 2 headphone connections. A dual-mono power supply housed in its own dedicated aluminium chassis assures the highest sound quality.
The balance reference phono is truly a world-class phono stage for analog aficionados.
Specifications:
| MODE | MM / MC switchable (at bottom) Subsonic filter switchable @20Hz (-18dB / Oct) (at bottom) Stereo / Mono switchable |
| AMPLIFICATION | + 46dB (MM mode) + 66dB (MC mode) |
| INPUT LOAD | 50kΩ / 50pF (MM mode and MC mode) +150pF, +270pF, +400pF (MM mode) 10kΩ, 5kΩ, 1000Ω, 500Ω, 100Ω, 50Ω (MC mode) |
| RIAA ACCURACY | ± 0.1dB @ 20Hz - 100kHz |
| THD | < 0.001% (IEC A) |
| SIGNAL TO NOISE RATIO | - 89dB @ 5mV / MM mode (IEC A) - 79dB @ 500uV / MC mode(IEC A) |
| HEADROOM | > + 21dB @ 1kHz |
| MAX. OUTPUT VOLTAGE | > 12V |
| RIAA | 75μs / 318μs / 3180μs, 2 passive filter |
| CHANNEL SEPERATION | > 95dB @ 1kHz (IEC A) |
| OUTPUT IMPEDANCE | 150Ω (balanced XLR) 75Ω (unbalanced RCA) |
| INPUTS | unbalanced (RCA) balanced (XLR) |
| OUTPUTS | unbalanced (RCA) balanced (XLR) headphone output (2 × Jack: 6.3mm) |
| POWER CONSUMPTION | Max. consumption: 12 watts Standby mode: < 0.5 watts Off mode: 0.0 watts (by switching off at the rear of the machine) |
| TOTAL WEIGHT PREAMPLIFIER | Approx. 2.9kg |
| TOTAL WEIGHT POWER SUPPLY | Approx. 2.2kg |
| DIMENSIONS PREAMPLIFIER (W/D/H) | Approx. 240 × 145 × 78mm (158mm deepth with RCA) |
| DIMENSIONS PREAMPLIFIER (W/D/H) | Approx. 9.45 × 5.71 × 3.07 inches (6.22 inches deepth with RCA) |
| DIMENSIONS POWER SUPPLY (W/D/H) | Approx. 240 × 145 x 78mm |
| DIMENSIONS POWER SUPPLY (W/D/H): | Approx. 9.45 × 5.71 × 3.07 inches |
