Description
The X8 features eight Cirrus Logic CS43198 DAC chips in a true dual-mono parallel architecture, with four DACs operating in parallel per channel. Left and right channels are fully independent in power supply, circuit layout, and signal path, minimizing crosstalk and interference.
The parallel analog outputs are precisely summed to reduce noise and improve dynamic range, signal-to-noise ratio, and low-level detail, resulting in stable imaging and clear spatial presentation.
A dedicated high-speed data buffering and distribution circuit ensures all DACs operate within the same reference clock domain, maintaining precise synchronization and preventing timing mismatch.
The new Luxsin X8 features unique HP-EQ technology that applies real-time hardware-level EQ adjustments based on each headphone's measured frequency response. This enables a sound signature closely aligned with your choice of target curve, unlocking many audio experiences from any single pair of headphones.
The new Luxsin X8 supports custom EQ profiles with one-click switching, backed by a growing database of over 2500 measured headphone models.
Specifications:
236mm (L) × 236.8mm (W) × 64mm (H)
2750g
AC 100-120V/220-240V~50/60Hz
4' LCD (480*960)Touchscreen
Cirrus Logic CS43198 × 8
Ultra-low-noise, voltage-adjustable Linear Power Supply
Wi-Fi 2.4GHz / 5GHz
Qualcomm SXW5125 (BT 5.1)
Touchscreen, Mobile APP (Android/iOS), Web Browser, IR Remote(Optional)
25W
Power Cable ×1, USB-B cable ×1, 3.5mm to 6.35mm adapter ×1
For Local Upgrade
Support PCM 768kHz/32bit;DSD512(Native)
Support PCM 768kHz/32bit;DSD512(Native)
Support PCM 192kHz/24bit
Standard 3.5mm Connector
RCA
XLR
6.35mm (Unbalanced), 4.4mm (Balanced), 4 pin XLR (Balanced)
≥129.5dB
<-121.8dB @unweighted
≥133dB (1kHz@200kΩ)
<1.1uVrms
4.2Vrms (1kHz@200kΩ)
RCA Output Audio Characteristics
≥124.5dB
<-120dB @unweighted
≥125dB (1kHz@100kΩ)
<1.3uVrms
2.1Vrms (1kHz@100kΩ)
Performance and Parameters of Balanced Headphone Output(4.4mm/XLR4)
L+R≥4840mW+4840mW(16Ω,THD+N<1%)
<1Ω
<-117dB(1kHz/0dB@32Ω)
≥123dB
≥119dB (1kHz@32Ω)
Performance and Parameters of Unbalanced Headphone Output(6.35mm)
L+R≥2900mW+2900mW(16Ω,THD+N<1%)
<1Ω
<-115dB(1kHz/0dB@32Ω)
≥121dB
