Magnetar Audio UDP800 MKII 4K UHD Universal Disc and Media Player COMING SOON
Magnetar Audio UDP800 MKII 4K UHD Universal Disc and Media Player COMING SOON
ETA to be confirmed by Magnetar, but expected ETA is November. Please Pre-Order As Initial Quantities Will Be Limited. Thank You.
Couldn't load pickup availability
Free Express Shipping In Canada
Canadian Warranty
Professional Customer Experience
Description
ETA to be confirmed by Magnetar, but expected ETA is November. Please Pre-Order As Initial Quantities Will Be Limited. Thank You.
The new Magnetar UDP800 MKII universal disc player features advanced image and audio processing for stunning home cinema performance. With upgraded copper-core wiring, premium JST and Amphenol connectors, and a redesigned USB3.0 system, it delivers exceptional stability and compatibility with external drives. A TMDS retiming function enhances HDMI audio for richer, more detailed sound, while seven OPA1602 op-amps ensure low-noise, high-precision playback. Built for audiophiles and cinephiles alike, the UDP800 MKII sets a new benchmark in premium AV performance.
Features:
Roon Ready In Certification
Newly Redesigned 2.0 Audio Boards With Seven OPA1602 Op-Amps
TMDS Retiming On HDMI Audio Port
Enhanced USB 3.0 System With Isolated Power
Upgraded Copper Wiring And Amphenol/JST Connectors
Control 4 Support
Crestron Support
Specifications:
| Disc Formats | UHD Blu-ray, Blu-ray, Blu-ray 3D, DVD-Video, DVD-Audio, AVCHD, SACD, CD, Kodak Picture CD, CD-R/RW, DVD±R/RW, DVD±R DL, BD-R/RE |
| Analog audio | Stereo |
| Independent stereo analog audio | XLR balanced output, RCA output |
| Optical/coaxial audio | up to 2 channels /192kHz PCM, Dolby Digital, DTS |
| HDMI audio | up to 7.1 channel /192kHz PCM, up to 5.1 channel DSD, Bitstream |
| HDMI video | UHD 23.976/25/30/50/59.94/60hz, 1080 I/P, 720P, 576I/P, 480I/P, source direct |
| Frequency range | 20Hz-20kHz (±0.05dB) |
| Signal-to-noise ratio | ≥120dB |
| Total harmonic distortion + Noise | ≤0.01% |
| Output level | (RCA) 2. 1±0.2Vrms; (XLR) 4.2±0.4Vrms |
| Dynamic range | AGT: ≥120dB |
| Channel separation | >100dB (RCA); >120dB (XLR) |
| Power supply | AC 100-240V ~, 50/60Hz |
| Power consumption | <30W, Standby<0.5W |
| Size | 430mm x 300mm x 90mm |
| Weight | 6.8kg |
| Operating temperature | 5° C ~ 35° C (41° F ~ 95° F) |
| Operating humidity | 15% ~ 75% |
