Description
NAD's CI SA2-120 is designed with scalability, flexibility, and reliability in mind. The SA2-120 has a versatile amplifier platform which can be used in a 2 x 120 wpc stereo system or a 4 x 60 wpc configuration via the additional pair of outputs with Dynamic Load Management, determining the way the amplifier will distribute its power. With its minimal rack space requirements (1/3 width x 1U height), the CI SA2-120 still manages to pack in a 2 x 120W DirectDigital™ amplifier with built-in thermostatic cooling to drive air circulation and allow amplifier stacking in a rack. Add in the award-winning multi-room music management platform, BluOS, and it strikes the perfect balance between size and function. Additionally, the device can be used in a Main Zone/Sub Zone configuration within BluOS, which adds independent volume control for the 2 pairs of speaker outputs, making it ideal for extended areas like a bedroom with ensuite.
Key Features:
2 x 120 wpc or 4 x 60 wpc of DirectDigital™ amplification
Dynamic Load Management auto-detects number of connected speakers to direct appropriate power to outputs
Compact 1/3 width x 1U height rack size
BluOS Enabled
Main Zone/Sub Zone configuration
WiFi and ethernet network connectivity
Apple AirPlay 2, Spotify Connect
Inputs: HDMI eARC, 3.5mm analogue/mini Toslink (all with Dolby Decoding), Bluetooth
Outputs: Main Zone sub out, 2 x 4-pin Phoenix connectors with tool-free snap on block connectors
Robust drivers for Control4, NICE, RTI, URC, Lutron, Crestron, Josh.ai, and other popular control systems
Monitor and troubleshoot remotely with Domotz
Dirac Live Ready
Flexible wall or rack mount, and surface placement options
Automatic thermostatic fan cooling
Specifications:
AUDIO
• Supported Audio File Formats
• MP3, AAC, WMA, WMA-L, OGG, OPUS
• Supported High-Quality Audio File Formats
• FLAC, MQA, ALAC, WAV, AIFF, MPEG-4 SLS
• Supported Multi-Channel Audio Formats
• Dolby Digital® Downmixing to stereo PCM
• Native Sampling Rates
• up to 192 KHz
• Bit Depth
• 16-24
• Audio Controls & EQ
• BluOS Control App
• Signal-to-Noise Ratio
• -102dBA
• Distortion
• THD+N, 0.005%
• Amplification
• DirectDigital™
• Rated Power Output
• Dynamic Power Management – 120W x 2 or 60W x 4 (8 Ohms)
• IHF Dynamic Power
• 300W (4ohm)/200w (8ohm)
SOFTWARE & INTEGRATIONS
• Operating System
• BluOS
• App Controller Operating System
• iOS, Android, Windows, macOS
• Processor
• ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
• Supported Network File Sharing
• Server Message Block (SMB) up to 200,000 files
• Album Art Supported
• JPG, PNG
• Music Services & Internet Radio
• 23+
• 3rd-Party Integrations
• AirPlay 2, Spotify Connect, Tidal Connect
• Room Correction Software
• Dirac Live Ready (In 2.1 configuration only, calibration mic not included)
• Control System Integrations
• Creston, Control4, RTI, Nice, URC, Lutron, Gira, Rako, Rithum, Free@Home, Josh.AI
• Voice Control Integrations
• Amazon Alexa Skills
CONNECTIONS
• Power Supply
• Universal 2-pin AC cord input (100-240AC)
• Ethernet/LAN
• Ethernet RJ45, Gigabit 1000Mbps
• Wi-Fi
• Built In WiFi 5 (802.11ac), dual-band
• Bluetooth Quality
• Bluetooth 5.2 aptX HD
• Bluetooth Connectivity
• Two-Way
• IR Optical Built In
• No
• IR Input
• 2-pin PHX connector (IR extender kit required)
• Optical/Analog Input
• Toslink Optical, 3.5mm Analog
• HDMI Input
• HDMI eARC
• USB In
• Type A (Fat32, NTFS Formatted) – External Storage Only
•
• Local Server Mode
• Dual Speaker Outputs
• Yes
• Main Zone/Sub Zone Capability
• Yes (independent volume control over Speaker Output 2 when activated)
• Subwoofer Output
• RCA x 1; Wireless to PULSE SUB+ (Linked to Output1/Main Zone only)
• Speaker Terminals
• 2x 4-PIN Snap On PHX 5.08mm Connector, supports up to 12AWG
• Headphone Output
• None
• 12v Trigger Input
• x1 Programmable Trigger Input
• 12v Trigger Output
• None
USER INTERFACE & CONTROL
• Status Indicator
• BluOS Status LED
• Source Status Indicator
• x2, BluOS/Connected Input Live
• Output Status Indicator
• x2, Output pair 1, Output Pair 2
GENERAL
• Finish
• Black
• Max Power Consumption
• 240w
• Storage Environment
• -10°C to 50°C, 20% to 80% relative humidity
• Operating Environment
• 0°C to 40°C
• SKU/Version
• SA2-120
• Generation
• 1
