Stax SRM-500T Electrostatic Headphone Amplifier

Stax SRM-500T Electrostatic Headphone Amplifier

Regular price $1,999.00
Regular price Sale price $1,999.00
Sale Featured Sold out
Free Express Shipping In Canada

No Discount Possible on this Product

Affirm Cannot Be Used With This Product

Free Express Shipping In Canada

Canadian Warranty

Professional Customer Experience

View full details

Description



Usually Ships Within 2 Days.





Custom-made low noise DUAL FET is installed on First Stage and the vacuum tube”6FQ7/6CG7″ is installed on Output Stage. STAX continued to use the traditional circuit design which is perfect for STAX vacuum tube driver and improved the power efficiency. The newly designed power transformer with the winding for the low voltage circuit is installed in SRM-500T. The low voltage winding enables to improve the power efficiency and achieve further power saving and better sound quality than the conventional vacuum tube output driver units.

Specifications:

●Type: FET input + vacuum tube output hybrid DC amplification driver unit
●Vacuum tube: 6FQ7/6CG7
●Gain: 60dB
●Harmonic distortion: 0.01% or less (1kHz/100Vrms output)
●Input impedance: 50kΩ (RCA), 50kΩx 2 (XLR)
●Maximum output voltage: 300Vrms (1kHz)
●Bias voltage: DC580V
●Operating temperature / humidity: 0 to 35 degrees C / less than 90% (non condensing)
●Input terminal: RCA x 1, XLR x 1
●Output: RCA parallel output terminal
●Power consumption: 38W
