Description
Dynavector's P75 stands as a complete phono solution, conveniently packed into a compact unit. It offers user-adjustable settings and the versatility to accommodate virtually any cartridge available in today's market. The P75 takes your audio experience to the next level with its unique "Phono Enhancer" (PE) feature. PE extracts the current signal and enhances the magnetic field within the cartridge itself, resulting in an even more captivating and musical performance. Experience an unprecedented level of accuracy with the P75, boasting extreme RIAA accuracy that faithfully reproduces your vinyl records. Say goodbye to unwanted noise, as the P75 offers exceptionally low noise levels, ensuring your music remains crystal clear. Plus, revel in the outstanding dynamic range that captures every musical nuance. The P75 mk4 introduces a groundbreaking ultra-low noise power supply, electrically isolated from the input power source. This innovative design takes the low-grade single voltage DC supply from the AC adapter and converts it into dual high voltages, achieving true professional-grade audio reproduction. Power supply noise becomes virtually undetectable, eliminating the hum problems that conventional phono amplifiers often encounter, thanks to the absence of mains frequency or low-frequency components.
Features:
New ultra-low-noise internal power supplies
Electrically isolated from AC power adaptor
On/off switch on back panel for extra convenience
Power efficiency doubled
Improved phono amplifier stage design
Ultra-precision custom components for extreme RIAA accuracy
New high-current output line driver for long interconnects
Outstanding noise rejection includes immunity from radio-station interference
Simplified adjustment, simplified jumper layout
More loading options
Adjustable MM capacitance loading
Matches virtually any cartridge on the market regardless of type
Fully user adjustable
All-new glass front-panel system
Custom-made black stainless fasteners and DV Gold ground terminal
|
SPECIFICATIONS: |
|||
|
The P-75 is a stand-alone phono to line level amplifier. It can operate with the following cartridge types: |
|||
|
Cartridge Type |
Input Sensitivity |
Gain |
Loading |
|
Low output MC |
0.2mV or 0.15mV |
60 & 63dB |
30, 100, 470 ohms |
|
Low output MC |
- |
- |
Zero ohms |
|
High output MC MM, MI |
2mV |
40dB |
47k (47,000) ohms |
|
Dimensions ( W x D x H ) |
133W x 83D x 44H mm |
||
|
Weight |
400g |
||
|
*Input sensitivity and gain is determined mainly by the cartridge internal resistance. Three resistance/gain adjustments available. |
|||
